CAH U-3550 dual channel, non-diversity, wireless microphone system
HK$1 650.00
現貨
产品详情
The U-3550 is a dual channel, non-diversity, PLL synthesized wireless microphone system that operates in the frequency range of UHF 760 - 950 MHz. It has a built-in sophisticated CPU that can automatically differentiate the receiving signal strength from the 2 antennas of the receiver and adjust the system to the antenna that has the stronger receiving signal to avoid signal dropouts and noise interference. The system is also equipped with the latest “NOISE LOCK” dual-squelch circuitry to prevent undesired random noise interference.
Features:
• 19" EIA Standard Rackmount
• RF, AF Signal Indicators
• High Sensitivity and S/N Ratio
• Robust Ergonomically Designed Handheld Transmitter
• Balanced & Unbalanced Outputs
Specifications:
Oscillation Mode: PLL Synthesized
Carrier Frequency Range: UHF 760.00 - 950.00MHz
requency: 20 non-interference fixed frequencies
Stability: ± 0.005%
Max Deviation: 68kHz with level limiting
Dynamic Range: > 110 dB
S/N Ratio: > 105 dB (A)
T.H.D.: < 0.5% @ 1kHz
Squelch: "NOISE LOCK" Dual-squelch
Frequency Response: 60Hz - 18kHz ± 3dB
